Hello everyone/你好
It’s been a while, dumboy here.
Fulfillment for the first chapter, Début: Diversity, was completed last year. Thanks to your incredible support, everything went according to plan. And the keeb gained a lot of compliments. Nearly a year has passed since the Diversity IC:re. It is finally time to move forward and unveil what’s behind the next curtain.
Here it is, scene 1: Dyad.

Exploded view

Specifications
Layout: F12 TKL
Mounting: Plate oring
Size: 359.61 mm * 136.01 mm (TKL) / 88.15 mm * 136.01 mm (Pad)
Weight(Unbuilt): 2.52kg (TKL) / 0.55kg (Pad)
Front height: 18.90mm (TKL&Pad)
EKH: 23.76mm (TKL&Pad)
Typing angle: 7°
Manufacturer(uncertain): Dadesin(DDS)

Color options
Black and silver are confirmed, other three colors will be voted in keyspensory dc channel.
Black

Match with GMK Tokyo Nights

Silver

Match with GMK Müt

PC

Match with GMK Finer Things

Cyan

Match with GMK Analog Dreams R2

Sand

Match with my friend's design Jazz

Pink

Match with GMK Hooty

Blue

Match with GMK Gorp

Purple

Match with GMK Lavender

Layouts
Soldering: F12/F13, split backspace, stepped capslock, ansi/iso enter, split left shift, split right shift, 6.25u/7u
Hotswap: Split backspace, Stepped capslock

Plates
Default plate is black alu, black PP/black CF/yellow PEI is optional

The rendering is 7u ansi only, the plate in GB will be more compatible.

PCBs
Default is 1.6mm soldering PCB, 1.6mm howswap/0.8mm soldering is optional.
Soldering

Hotswap

What's inside?
TKL:
1.Delivery box * 1
2.Carrying bag * 1
3.Keyboard cloth * 1
4.Case * 1
5.Plate * 1
6.PCB * 1
7.Oring * 2
8.Foams * 1
9.Daughter board * 1
10. Bumpon * 6
11. Screws * n
12. Manual * 1

Pad:
1.Delivery box * 1
2.Keyboard cloth * 1
3.Case * 1
4.Plate * 1
5.PCB * 1
6.Oring * 2
7.Foams * 1
8.Daughter board * 1
9. Bumpon * 6
10. Screws * n
11. Manual * 1

Typing test
This is a simple proto from JLC, and more photos and videos of protos from dds will be updated here.
【Dyad proto typing test】

Estimate price
Starting at $480
+shipping from CN mainland
Extra PCB/plate price will be listed on GB
MOQ: 100
Delivery time: within 5 months once GB ends (depends on the orders)

Estimate GB time
Around 2026.5.10
International: keyspensory
Some regional vendors will be announced later.
