Description

Hello, this is Moyu.studio

This time, we bring you a lightweight, high-performance magnetic switch - Yurui HE switch

Yurui HE switch specification
Top Housing: PC
Bottom Housing: Nylon
Stem: POM
Spring: 20mm
Total Travel: 3.6±0.2mm
Operating Force: 37±2g
Bottom-out Force: 42±2g
Bottom-out Magnetic Flux: 630±40GS
Lubed

At the beginning of the design, we aimed to create a high-performance, long-lasting HE switch with a high level of appearance and cost-effectiveness.
After trying several springs, we chose to customize this 42g extended spring.
The design of the extended spring can make the switch more responsive during rebound, improving the accuracy of hovering.
The design of dust-proof stem makes the stem more stable and avoids stem shaking.
In terms of exterior design, we used three different shades of green for matching, and added gold glitter on the top cover.
The combination of three different green colors on different materials presents a more harmonious texture.
In terms of materials, we have chosen the classic combination of POM, PC, and PA66, which is stable and durable
In terms of lubrication, we have adopted a lightweight lubrication scheme, using only a small amount of grease on both sides of the stem's small feet and the bottom of the spring for lubrication, and dry film lubrication for the stem's pillars
Bringing a drier and less greasy feel, and also more convenient for DIY in the future

Sales method: Inventory sales
Price：0.23＄/PCS(Adjustments will be made according to the region）
Vendor List:
US:TBD
Vietnam：TBD
CA:TBD
EU:TBD
UK:TBD
Japan：TBD
Singapore:TBD
AUS:TBD
Malaysia：TBD
Korea：TBD
Rest of the world:Moyu.studio
