Updates:0426:
New Southpaw solder PCB layout with non-mirrored numpad support.(Chech the layout pic below)
Full copper/Brass SE version update (Details in discord):
https://cdn.shopify.com/s/files/1/0607/5351/0626/files/30-7.png?v=1714109192Retro Ewhite with E yellow IRL pic update.
0506:
GB onging now!
Full Brass/Copper SE version updated:
https://www.mmkeyboard.com/products/class-0413-se-barebone-onlyhttps://www.mmkeyboard.com/products/class-0413-se-top-frame
Hi Everyboday,We are MM Studio! After our more optimization and tests, today we finally finished class0413.
Thansks for your support and patience so much again!
An AT layout keyboard with multiple color/layout top frame options. South paw version available.
EC PCB and solenoid/buzzer supported.
Changes from IC
1.New Type C connector design:
A srcew in full brass piece to settle the daughter board and solenoid/buzzer.
2.South Paw Version available:
South paw version with mirrored numpad in the left and macro in the right.
Notice: South paw top frame and bottom case can’t fit normal version frame or bottom case.
South Paw Solder PCB layout:
South Paw Hotswap PCB layout:
Renders:
3.Top mount side fixing point removed.
Keyboard info：
5 different layout top frame and 9 different colors:
PCB Gasket and Top mount supported. EC PCB available too.
All PCB are solenoid/buzzer supported.
[/b]
Rivet screw fixed retro badge with keyboard ID num.
Full brass inner weight.
Keyboard options：
Bottom case color：
Ano Black, Ano Silver, E-white
Top frame color:
Ano Burgendy, Ano Dark Gold, E-Yellow, E-Retro Gray, Ano Dark Green, Ano Brown, Ano Sand Gold, Ano Gray, Ano Silver
Top frame Layout：
Standard: WK, Arrowkey, WKL
South Paw: WKL, WK
Plate：
PC, Ano Black Alu, Copper, Brass
[/size]
EC plate:
Black sand blasted PVD SS (Topre)
Notice: Topre build are required to cut the housing to suit the housing into the plate duel to the top frame fixing screw holes so beginners are not recommended to pick this option.
PCB：
Standard Layout ：
Soldering PCB (5mm Poron included)
[/size]
Hotswap PCB：
EC PCB: (The plate is single layout supported(2u BS , non split RS), need to customize plate to use other layout)
South Paw Layout：
Soldering PCB (5mm Poron included)
Hotswap PCB：
Group Buy Details
Keyboard Price:
Base Keyboard Kit Price：360$
Extra top Frame: 60$
Upgrade to Brass/Copper plate: 30$
More detailed price please check our website:
GB Date: May 6th - May 20th
Estimated Delivery to vendors: 3-4 months after GB ended
Vendor list:
US: Divinikey
CA: Ashkeebs
UK：Mechboards
EU: Keygem
KR: Swagkeys
VN: MOKB
TW: Inpad
TH: NTCH keys
PH: Zion Studio
AU: Switchkeys
JP: Basekeys
Others: MM Studio
Specifications
Keyboard Size:
Weight：4.6kg case only
Front height: 19.27mm
Typing Angle: 7°
Mounting method: Top or Gasket (Plateless supported)
PCB：QMK-VIAL
Case material: 6063 Aluminum
Inner weight material : Brass with antioxidant treatment
Keyboard Includes：
Case and top frame
Brass inner weight
Brass daughter board port
Brass badge
Solenoid/buzzer typec daughter board
Plate
PCB
Accessories pack
Foam kit (3.5mm Plate foam, Ixpe foam, 2mm case foam)
Packing box
Medias:
Earlier Prototype Video:
GB Prototype Pics and Video:（More coming in a week）
Retro Ewhite & E yellow, Southpaw
Join our Discord to get newest update :https://discord.gg/JwhcamtBGS
